Measurement objects

Whole blood or hemolysis sample

Measured items

Fast Mode: HbA1c (Stable HbA1c, S-A1c) and HbF
Variant Mode: HbA1c (Stable HbA1c, S-A1c) and HbF (HbS and HbC separation and HbE and HbD detection can be performed).

Measurement principle

Reversed-phase cation exchange chromatography

Measurement wavelength

420 nm/500 nm (Dual-wavelength colorimetry)

Resolution

0.1% Ratio, 1 mmol/mol

Measurement range

HbA1c: 3 – 20%, 9 – 195 mmol/mol
HbF: 0 – 100%

Processing speed

Variant mode: 160 seconds/test
Fast mode: 100 seconds/test

Sample consumption

Whole blood sample: Approximately 4µL
Anemia sample: Approximately 8 µL
Hemolysis sample: Approximately 350 µL

Sample container

Sample tube:
(12.3 or 15 mm in outer diameter) × (75 to 100 mm in height)
Sample cup: 500 µL

Sample supply

Piercing sampling

Compatible rack type

ARKRAY racks (for 5 samples)

Operating environment

Temperature: 10 – 30°C;
Humidity: 20 – 80% RH (No condensation)

Display

20 digits × 2 lines LCD

Printer

For use with 58-mm width thermal printer paper

Number of measurement samples

Maximum 10 samples

Power requirements

AC 100 – 240 V±10%, 50/60 Hz

Dimensions

330 (W) × 515 (D) × 485 (H) mm
(Not including protrusions, eluent packs and hemolysis washing solution bottle)
